功用与百科/Brief Introduction：

此机选用特定三通管件装罐阀，可广泛用于于水剂和膏霜类护肤品的装罐，格外对高黏度废料（如浓酱、干辣椒酱、番茄酱、种衣剂、微乳剂、浮悬剂等）的感觉是比较分明，且gps精程度高。此机选用PLC可程序设计操纵，配上6英尺触碰屏人与机器程序界面软件系统，执行全电脑自主进瓶，全电脑自主装罐，全电脑自主出瓶，电气，汽动元的结构件均选用国际联盟企业，保证了好品质的效果和男人持久平稳的性能参数。本机的结构非常简单，基本操作方便简洁，是全球满意的面对高黏度废料的装罐机。此机人员配备了杜绝渗漏问题与磨砂工艺的装罐闷头，保证装罐及时后无渗漏问题，无磨砂工艺。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特性/Characteristic：

◆调节机系统——利用三凌PLC调节机系统，装灌使用量随机函数稍微调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运行画面——69英寸彩屏手触式运行画面，形象化简单、健康安全准确Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆的职能加强——排料有防滴漏问题平衡装置，可要根据材料形态提供下潜装罐的职能。（此的职能可能使用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器开关元器件——均适用香港国际顶级产品，切实保障设施设备的安会稳定可靠、正确性强；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机诫控制核心部件——仪器控制核心部件均分为品质304不锈铝设计制作,深表歉意要有接处货位会分为316L另收取用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算测量——时时运算，对事业产出量直观教学反映出。Counting test, real-time, intuitive reflect the yield of work.◆罐装监测——无瓶不灌、瓶数不能不灌Bottle filling test - no bottle no filling, not enough◆定期检查前提——机器满足GMP必须，可随意卸下来、难以清理定期检查。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆换成規格——换成装灌規格时，只需要方便整改，方便搞懂。Changing specifications - change the filling specifications, simply adjust, easy fix.◆场景性能——性能了场景的框架，使工具的运行场景更进一步的清洁安全卫生。（此场景性能需要选用）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

水平技术指标/technical parameters：

包装头数The number of filling head	8头（自选4、6、8、10、11个灌装设备头）8 head (optiona🐟l 4, 6, 8, 10, 12 fillinꦚg head)
符合瓶径 Applicable bottles Drive	Ф33-Ф100 mm
检定计算精度measure precision	±1%
罐装容积Canned capacity	150-1000ml
生产销售学习能力Production Capacity	2400-4000瓶/1天2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
